0. SWINGINGARM ASSY, REAR(GD250) 61000HC8100HPA
1. SWINGINGARM COMP, REAR RH 61110HC8101
1-1 S/ARM REAR ASSY RH (GD250N) 61110HC8100HPA
2. S/ARM COMP, REAR LH (GD250N) 61120HC8101
2-1 S/ARM REAR ASSY LH (GD250N) 61120HC8100HPA
3. BUSH (TE50) 09319H10055
4. BEARING,REAR SWING 09263-22017
5. SPC, S/ARM PIVOT BEARING (GD25 61251HC8100
6. SHAFT,REAR S/ARM PIVOT(GD250N) 61211HC8100
7. SHIM,REVER IDLE GR THRUST(TE45 09181H17002
8. NUT,SWING ARM PIVOT 08319-31128
9. DUST SEAT,RR S/ARM PIVOT(TE450 09284H38003
10. SEAL,FRONT HUB R/L INNER(TE450 09284-26002
11. BOLT,PILLTON FOOTREST RH 01517-10458
12. NUT,FRONT SORBER 08319-31108
13. PIN,CRANK CASE (GT&GV) 04213-13189
14. BUFFER, CHAIN DEFENSE(GD250N) 61273HC8101
15. SCREW,LEG SHIELD LOWER 02142-06165
16. WASHER 09169H06011
17. BOLT,CHAIN ADJUSTER 09103H08608
